XRotor PRO 40A ESC (Dual Pack)
This package comes with "2 ESCs"
HOBBYWING ESC
Master of Multicopter
Dual Pack ="2 X ESCs"
|
Model: XROTOR ESC
|
40A | PRO 40A |
PRO 40A (COB) |
| MAP | $17.99 | $49.99 | $49.99 |
| SKU | 30901001 | 30902042 | 30902041 |
| Comes with | 1 ESC | 2 ESCs | 2 ESCs |
|
Cont./Peak Current
|
40A/60A | 40A/60A | 40A/60A |
| Multicopter Applicable | 550/650 Class Quadcopter | 550/650 Class Quadcopter | 550/650 Class Quadcopter |
| Input / | 2S-6S | 3-6S Lipo | 3-6S Lipo |
| Bullet connector size | 3.5mm | 3.5mm | 3.5mm |
| BEC Type / BEC Output | NO | NO | NO |
| Programming item |
Timing (High/Intermediate), | ON/OFF of the DEO function | ON/OFF of the DEO function |
| Size / Weight |
68 x 25 x 8.7mm 26g (0.92oz) |
66x21.8x11mm ~12.4mm @ capacitor 26g (0.92oz) 50g |
73.5x21.8x11mm ~12.4mm @ capacitor 26g (0.92oz) 45g |
- Special core program for multi-rotor controllers greatly improves throttle response.
- Specially optimized software for excellent compatibility with disc-type motors.
- All settings except the "Timing" are preset, making usage simple, highly intelligent and adaptive.
- The twisted-pair design of the throttle signal cable effectively reduces the crosstalk produced in signal transmission and makes flight more stable.
- Compatible with various flight-control systems and supports a signal frequency of up to 621Hz (Note: all throttle signals over 500Hz are non-standard signals) .
- Special drive chip has much better MOSFET driving effect than common driving circuit consisted of discrete components.
- MOSFET with extra-low resistance brings high performance and great current endurance.
|
Model: XROTOR ESC
|
PRO 40A |
PRO 40A (COB) |
| SKU | 30902005 | 30902004 |
|
Cont./Peak Current
|
40A/60A | 40A/60A |
| Multicopter Applicable | 550/650 Class Quadcopter | 550/650 Class Quadcopter |
| Input / | 3-6S Lipo | 3-6S Lipo |
| Bullet connector size | 3mm | 3mm |
| BEC Type / BEC Output | NO | NO |
| Programming item |
ON/OFF of the DEO function | ON/OFF of the DEO function |
| Size / Weight | 66x21.8x11mm 50g |
73.5x21.8x11mm 45g |
*OPTO: there is no built-in BEC
COB: You can connect your motor wire 'directly' to the ESC. so there is no motor wire coming out of the ESC
Official Warranty Available through HobbywingDirect.com & FS authorized dealer network in North America
For more information: http://www.HobbywingDirect.com/pages/rma
