High Performance Cooling Fan for ESCs

AXE R1/R2 ESC
Xerun Stock Spec / 1s HD
XERUN-120A V2.1 SD /Xerun 90A & 60A
Ezrun WP 60A, 80A, Ezrun 60A
Justock & Xtreme
EZRUN MAX10 & MAX10-SCT
QUICRUN 1080 / 1080 G2 / 880 Dual

Use instructions:

Please choose the correct cooling fans for different applications.
        For 4-6 cell NiMH or 2S LiPo: No need to change the 5V cooling fan on the ESC
        For 7-9 cell NiMH or 3S LiPo: Please choose a 12V cooling fan or supply the 5V fan from the receiver (+6V)
        For 10-12 cell NiMH or 4S LiPo: Please choose a 12V cooling fan, and cut the output of the built-in BEC. Then supply the receiver with a UBEC (An additional external DC-DC regulator)

Specification

Size: 5V: 24.5mm (L) * 24.5mm (W) * 10mm (H)
Weight: 7.2g

>> See All HOBBYWING Cooling Fan

High-Performance Cooling Fans for HOBBYWING ESCs come in various sizes and power voltages. Each unit is checked and approved via ISO 9001 Quality Control procedure.

ESC	Model p/n	Input	Feature
AXE R2	2510BH-6V-0.27A-BLACK-B (30860007)		2510BH-6V-18000RPM@6V-0.27A
AXE R1/R2, QUICRUN WP 880	FANP 2510 JR3P 200mm (3086000)		JR3P 200mm 5V BlackE
Quicrun 10bl120	2510SH-5V-0.13A Black E (30860003)		5V/10000RPM/ Max 7.2V Copper bush/non-waterproof wire length=30MM
Justock G3 Quicrun 10bl60	2510SH-5V Black B (86080050)	4-5cells NiMh/NiCd or 2 cells LiPo	5V/10000RPM/ Max 7.2V Copper bush/non-waterproof plug: ZH-2Ymale, wire length=30MM
Ezrun 60A Justock Xtreme	MP2510SH-12V Black A (86080051)	7-12 cell NiMh/NiCd or 3 cell LiPo	12V/14000RPM Copper bush/splashproof plug: ZH-2Y male, wire length=30MM
Ezrun WP 60A SL Ezrun WP 80A SL	MP2510SH-5V Black A (86080052)	4-5 cell NiMh/NiCd or 2 cell LiPo	5V/10000RPM/ Max 7.2V Copper bush/Splashproof plug: ZH-3Y male, wire length=35MM
Ezrun MAX10 Ezrun MAX10 SCT QUICRUN 1080 WP	MP2510SH-6V-0.17A-BLACK (30860005)		6V/12000RPM plug: JR-3P Male
